Android Program to Demonstrate using Subscreen in a Preference Screen

Here is source code of the Program to Demonstrate Subscreen in a Prefernce Screen in Android. The program is successfully compiled and run on a Windows system using Eclipse Ide. The program output is also shown below.

If you want to place groups of settings into a subscreen , place the group of Preference objects inside a PreferenceScreen.

MainActivity.java

package com.example.usingsubscreen;

import android.app.Activity;
import android.content.Intent;
import android.content.SharedPreferences;
import android.os.Bundle;
import android.preference.PreferenceManager;
import android.view.Menu;
import android.view.View;
import android.widget.Button;
import android.widget.TextView;

public class MainActivity extends Activity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        Button but2 = (Button) findViewById(R.id.button1);
        but2.setOnClickListener(new View.OnClickListener() {

            Intent in = new Intent("com.example.usingsubscreen.Pref");

            @Override
            public void onClick(View v) {
                // TODO Auto-generated method stub
                startActivity(in);
            }
        });
    }

    @Override
    public boolean onCreateOptionsMenu(Menu menu) {
        // Inflate the menu; this adds items to the action bar if it is present.
        getMenuInflater().inflate(R.menu.main, menu);
        return true;
    }

}

Pref.java

package com.example.usingsubscreen;

import android.os.Bundle;
import android.preference.PreferenceActivity;

public class Pref extends PreferenceActivity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        // TODO Auto-generated method stub
        super.onCreate(savedInstanceState);
        addPreferencesFromResource(R.xml.pref);
    }

}

Activity_main.xml

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".MainActivity" >

    <Button
        android:id="@+id/button1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentLeft="true"
        android:layout_alignParentRight="true"
        android:layout_centerVertical="true"
        android:text="LAUNCH" />

</RelativeLayout>

pref.xml

Sanfoundry Certification Contest of the Month is Live. 100+ Subjects. Participate Now!

<?xml version="1.0" encoding="utf-8"?>
<PreferenceScreen xmlns:android="http://schemas.android.com/apk/res/android"
    android:title="...." >

    <PreferenceScreen
        android:key="button_voicemail_category_key"
        android:title="voicemail"
        android:persistent="false">
        <ListPreference
            android:key="button_voicemail_provider_key"
            android:title="voicemail_provider"/>
        <!-- opens another nested subscreen -->
        <PreferenceScreen
            android:key="button_voicemail_setting_key"
            android:title="voicemail_settings"
            android:persistent="false">
            ...
        </PreferenceScreen>
        <RingtonePreference
            android:key="button_voicemail_ringtone_key"
            android:title="voicemail_ringtone_title"
            android:ringtoneType="notification" />
        ...
    </PreferenceScreen>
</PreferenceScreen>

AndroidManifest.xml

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.example.usingsubscreen"
    android:versionCode="1"
    android:versionName="1.0" >

    <uses-sdk
        android:minSdkVersion="11"
        android:targetSdkVersion="17" />

    <application
        android:allowBackup="true"
        android:icon="@drawable/ic_launcher"
        android:label="@string/app_name"
        android:theme="@style/AppTheme" >
        <activity
            android:name="com.example.usingsubscreen.MainActivity"
            android:label="@string/app_name" >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
        <activity
            android:name="com.example.usingsubscreen.Pref"
            android:theme="@android:style/Theme.Black.NoTitleBar" >
            <intent-filter>
                <action android:name="com.example.usingsubscreen.Pref" />

                <category android:name="android.intent.category.DEFAULT" />
            </intent-filter>
        </activity>
    </application>

</manifest>

Sanfoundry Global Education & Learning Series – 100+ Java Android Tutorials.

If you wish to look at all Tutorials, go to Java Android Tutorials.

If you find any mistake above, kindly email to [email protected]
